ZKTEco MiniTA เป็นเครื่องสแกนใบหน้า บันทึกข้อมูลบันทึกเวลา ขนาดเล็ก ใช้ระบบปฏิบัตการ Linux พร้อมเทคโนโลยี Visible Light Facial Recognition การออกแบบที่กะทัดรัดเป็นพิเศษทำให้ติดตั้งได้อย่างสวยงามและง่ายดายแม้ในพื้นที่แคบ นอกจากนี้อุปกรณ์ยังประกอบด้วยไฟ LED ในตัวพร้อมฟังก์ชั่นปรับความสว่างเพื่อการตรวจสอบผู้ใช้อย่างต่อเนื่องในเวลากลางคืนหรือสถานที่มืด ที่ๆมีแสงน้อย
Technical Specifications | |
---|---|
Face Capacity |
800 |
User Capacity |
800 |
Record Capacity |
150,000 |
Display |
2.8-inch Screen |
Communication |
Wifi |
Standard Functions |
Web Server, SMS, Automatic Status Switch,Self-Service Query, Work Code, T9 input, 9 Digits User ID, DST, Schedule Bell |
Optional Functions |
ADMS |
Software |
ZKTime. Net |
Power Supply |
DC 5V 0.8A |
Verification Speed |
≤1 sec |
Operating Temp. |
0 C- 45 C |
Operating Humidity |
20%-80% |
Dimension |
10 x 10 x 2.4 cm (Length x Width x Thickness) |
Net Weight |
0.42 kg |
ZKTeco Eface10 คือเครื่องสแกนใบหน้าและควบคุม เปิด-ปิด ประตู ที่มาพร้อมกับเทคโนโลยีใหม่ Visible Light Face ที่ช่วยให้อ่านใบหน้าได้ไวและรวดเร็วแม่นยำมากขึ้น ทั้งนี้ยังสามารถสแกนในที่ย้อนแสงหรือแสงน้อยได้ดี เพราะตัว ZKTeco Eface10 มี LED ที่ช่วยในการอ่านใบหน้า นอกจากนั้นยังมีเทคโนโลยีการป้องกันการปลอมแปลงจากการสแกนผ่านจากรูปถ่าย หรือวิดิโอ ทั้งภาพถ่ายจริงหรือในโทรศัพท์ ซึ่งทำให้การใช้งานเครื่องสแกนใบหน้า ZKTeco Eface10 มีความปลอดภัยเป็นอย่างมาก และที่นอกเหนือจากนั้น ZKTeco Eface10 สามารถสแกนใบหน้าขณะที่สวมหน้ากากได้ แต่การสวมหน้ากากต้องไม่ปิดบัง 70% ของใบหน้า ซึ่งทำให้ลดการสัมผัส ลดความเสียงจากโรคติดต่อด้วย
คุณสมบัติ
>Visible Light Facail recognition
>Anit-spoofing algorithm against print attack (laser,color and B/W photos) videos attack and 3D mask attack
>Multiple verification methods:Face/Password/card(optional)
>card modules (optional):125KHz ID Card(EM)/13.56MHz IC Card
>support Standard wall-mounting with Backplat or optional wall-mounting with cable Box,and Optional desktop installation with Cable box
Technical Specifications | |
---|---|
Display |
4.3-inch Touch Screen |
Face Capacity |
500 |
Users Capacity |
1,000 |
ID Card Capacity(optional) |
1,000 |
Transection Capacity |
150,000 |
Communication |
TCP/IP,USB Host |
Standard Function |
ADMS,WorkCode,DST,Seft-Service Query,Autumatic Status Switch,T9 Input Camera,9-digit User ID,Multiple Verification Medthos,bell Scheduling |
Hardwear |
1GHz Dual-Core CPU,256MB RAM/512MB ROM,1MB Binocular Camera |
System |
Operation Linux |
Access Controll Interface |
3rd Party Electiv Lock,Door sensor,Exit Button |
Optional Function |
125KHz ID Card(EM)/13.56MHz IC Card,Battery Backup,Cable Box for Battery Installation and Storage |
Biometrics Algorithms |
ZKLiveFace V3.5 |
Facial Recognition Speed |
≤1s |
Power Supply |
12V 1.5A |
Operating Temperature |
0 - 45 °C |
Operating Humidity |
20% -80% |
Dimension(W×H×D)mm |
130×119×28mm |
Supported Software |
ZKBioAccess/ZKTime.Net/ZKBioTime8.0 |
Working Temperature |
OPC to 45 °C |
ZKTeco MB10-VL คือเครื่องสแกนใบหน้าและลายนิ้วมือ
บันทึกเวลาทำงานควบคุมเปิด-ปิด ประตู
MB10-VL มาพร้อมกับเทคโนโลยี Visible Light Face ที่เป็นเทคโนโลยีใหม่ล่าสุดของ ZKTeco ที่สามารถสแกนในที่ย้อนแสงและในที่มืดได้ดี ระยะในการสแกนใบหน้าเริ่มจาก 0.3m ถึง 1.5m ทั้งนี้ยังมเทคโนโลยีที่ป้องกันการสแกนจากภาพถ่ายหรือวิดิโอ ทั้งภาพถ่ายจริงหรือในโทรศัพท์
คุณสมบัติ
>การสแกนใบหน้าด้วย Visible Light Face
> ป้องกันการปลอมแปลงโดยใช้รูปภาพ/วิดิโอ
>โหมดการตรวจสอบ ใบหน้า/ลายนิ้วมือ/การ์ด/รหัสผ่าน
>โมดูลการ์ดตัวเลือก 125KHz ID Card & 13.56MHz IC Card
>สามารถปรับแสงสว่างได้
Technical Specifications | |
---|---|
Display |
2.8 inch TFT LCD Color Screen |
Face Capacity |
100 |
Fingerprint Capacity |
500 |
Card Capacity Optional |
500 ID or Mifare card |
Transaction Capacity |
50,000 |
Algorithm Version |
ZKFinger VX10.0 & ZKFace V3.8 |
Communication |
TCP/IP,USB Host |
Access Control Interface |
3rd Party Electric Lock, Door Sensor, Exit Button |
Hardwaer |
1GHz Dual-Core CPU,256MB RAM/256MB Flash, 1MB Binocular Camera |
Standard Function |
ADMS,T9 Input,Alarm,Camera,Digit 9,Group,วันหยุด,ป้องกันการติดตาม,ค้นหาข้อมูล,ป้องกันการงัดแงะ,โหมดการตรวจสอบหลายแบบ |
Power Supply |
5V 2A |
Operating Temperature |
0 °C- 45 °C |
Operating Humidity |
20%-80% |
Size(WxDxL) |
168x151.5x31.7mm |
Software |
ZKTime.Net/ZKbioTime8.0 |
ZKTeco MB40-VL คือเครื่องสแกนใบหน้าและลายนิ้วมือ
บันทึกเวลาทำงานควบคุมเปิด-ปิด ประตู
MB40-VL มาพร้อมกับเทคโนโลยี Visible Light Face ที่เป็นเทคโนโลยีใหม่ล่าสุดของ ZKTeco ที่สามารถสแกนในที่ย้อนแสงและในที่มืดได้ดี ระยะในการสแกนใบหน้าเริ่มจาก 0.3m ถึง 1.5m ทั้งนี้ยังมีเทคโนโลยีที่ป้องกันการสแกนจากภาพถ่ายหรือวิดิโอ ทั้งภาพถ่ายจริงหรือในโทรศัพท์ นอกจากนั้น MB40-VL ยังมีการรองรับการเชื่อมต่อผ่านระบบ WIFI ทำให้การติดตั้งและการดึงข้อมูลบันทึกเวลานั้นสะดวกมากยิ่งขึ้น
คุณสมบัติ
>การสแกนใบหน้าด้วย Visible Light Face
> ป้องกันการปลอมแปลงโดยใช้รูปภาพ/วิดิโอ
>โหมดการตรวจสอบ ใบหน้า/ลายนิ้วมือ/การ์ด/รหัสผ่าน
>โมดูลการ์ดตัวเลือก 125KHz ID Card & 13.56MHz IC Card
>สามารถปรับแสงสว่างได้
Technical Specifications | |
---|---|
Display |
2.8 inch TFT LCD Color Screen |
Face Capacity |
3,000 |
Fingerprint Capacity |
3,000 |
Card Capacity Optional |
10,000 ID or Mifare card |
Transaction Capacity |
100,000 |
Algorithm Version |
ZKFinger VX10.0 & ZKFace V5.8 |
Communication |
WIFI,TCP/IP,Wiegand input/output,RS485,RS232 |
Access Control Interface |
3rd Party Electric Lock, Door Sensor, Exit Button, Alarm, Doorbell, Wiegand In/Out |
Hardwaer |
CPU Dual Core memory Ram 5MB/Rom 8G Camera 2MB |
Standard Function |
ADMS,T9 Input,Alarm,Camera,Digit 9,Group,วันหยุด,ป้องกันการติดตาม,ค้นหาข้อมูล,ป้องกันการงัดแงะ,โหมดการตรวจสอบหลายแบบ |
Power Supply |
12V 3A |
Operating Temperature |
0 °C- 45 °C |
Operating Humidity |
20%-80% |
Size(WxDxL) |
170x138x38.55mm |
Software |
ZKTime.Net/ZKbioTime8.0 |
ZKTeco MB360 คือเครื่องสแกนใบหน้าและลายนิ้วมือ
บันทึกเวลาทำงานควบคุมเปิด-ปิด ประตู
MB360 รองรับการสแกนใบหน้าและลายนิ้วมือ สามารถบันทึกเวลาในการทำงานและควบคุมเปิด-ปิด ประตู อีกชื่อนึงจะเรียกว่ารุ่น Thai02 ซึ่งรุ่นนี้จะมีฟังก์ชั่นการใช้งานระดับมาตราฐานใช้งาน และทนทานต่อการใช้งาน
คุณสมบัติ
>หน้าจอสี TFT 2.8 นิ้ว
>โหมดการตรวจสอบ ใบหน้า/ลายนิ้วมือ/การ์ด/รหัสผ่าน
>โมดูลการ์ดตัวเลือก 125KHz ID Card & 13.56MHz IC Card
>ควบคุมประตู
Technical Specifications | |
---|---|
Display |
2.8 inch TFT LCD Color Screen |
Face Capacity |
1,500 |
Fingerprint Capacity |
2,000 |
Card Capacity Optional |
2,000 ID or Mifare card |
Transaction Capacity |
100,000 |
Algorithm Version |
ZKFinger VX10.0 & ZKFace V3.8 |
Communication |
TCP/IP,USB Host |
Access Control Interface |
3rd Party Electric Lock, Door Sensor, Exit Button,Alarm |
Verification |
≤1s |
Standard Function |
ADMS,T9 Input,Alarm,Camera,Digit 9,Group,วันหยุด,ป้องกันการติดตาม,ค้นหาข้อมูล,ป้องกันการงัดแงะ,โหมดการตรวจสอบหลายแบบ |
Power Supply |
12V 1.5A |
Operating Temperature |
0 °C- 45 °C |
Operating Humidity |
20%-80% |
Size(WxDxL) |
167.5x148.8x32.2mm |
Software |
ZKTime.Net/ZKbioTime8.0 |
ZKTeco MB360 คือเครื่องสแกนใบหน้าและลายนิ้วมือ
บันทึกเวลาทำงานควบคุมเปิด-ปิด ประตู
MB360 รองรับการสแกนใบหน้าและลายนิ้วมือ สามารถบันทึกเวลาในการทำงานและควบคุมเปิด-ปิด ประตู อีกชื่อนึงจะเรียกว่ารุ่น Thai02 ซึ่งรุ่นนี้จะมีฟังก์ชั่นการใช้งานระดับมาตราฐานใช้งาน และทนทานต่อการใช้งาน
คุณสมบัติ
>หน้าจอสี TFT 2.8 นิ้ว
>โหมดการตรวจสอบ ใบหน้า/ลายนิ้วมือ/การ์ด/รหัสผ่าน
>โมดูลการ์ดตัวเลือก 125KHz ID Card & 13.56MHz IC Card
>ควบคุมประตู
Technical Specifications | |
---|---|
Display |
2.8 inch TFT LCD Color Screen |
Face Capacity |
1,500 |
Fingerprint Capacity |
2,000 |
Card Capacity Optional |
2,000 ID or Mifare card |
Transaction Capacity |
100,000 |
Algorithm Version |
ZKFinger VX10.0 & ZKFace V3.8 |
Communication |
TCP/IP,USB Host |
Access Control Interface |
3rd Party Electric Lock, Door Sensor, Exit Button,Alarm |
Verification |
≤1s |
Standard Function |
ADMS,T9 Input,Alarm,Camera,Digit 9,Group,วันหยุด,ป้องกันการติดตาม,ค้นหาข้อมูล,ป้องกันการงัดแงะ,โหมดการตรวจสอบหลายแบบ |
Power Supply |
12V 1.5A |
Operating Temperature |
0 °C- 45 °C |
Operating Humidity |
20%-80% |
Size(WxDxL) |
167.5x148.8x32.2mm |
Software |
ZKTime.Net/ZKbioTime8.0 |
SilkBio-100TC is the first ever Time & Attendance and Access Control Terminal to be associated with SilkID fingerprint reader, face recognition and RFID card functions. With the new SilkID fingerprint reader, the operation remain stable under strong light source and high preciseness of verification of wet and rough fingers. With latest facial algorithm and the innovation features, Silkbio-100TC is bringing you the whole new experience.
Technical Specifications | |
---|---|
Face Capacity |
800 |
Fingerprint Capacity |
1500 |
ID Card Capacity |
2,000 (Optional) |
Record Capacity |
100,000 |
Display |
2.8-inch TFT Screen |
Communication |
RS232/485, TCP/IP, USB -Host |
Standard Functions |
Work Code, SMS, DST, Scheduled-bell, Self-Service Query, Automatic Status Switch ,Photo ID, T9 Input, Camera, 9 digit user ID, Built-in Battery, Multiple Verify Mode, External Bell. |
Access Control Interface for |
Lock, Door Sensor, Exit Button, Alarm |
Wiegand Signal |
Output |
Optional Functions |
ID/Mifare, ADMS |
Power Supply |
DC 12V 3A |
Operating Temp. |
0 °C- 45 °C |
Operating Humidity |
20%-80% |
Dimension |
173.0×159.0×36.1mm (Length×Width×Thickness) |
Net Weight |
490 g |
SilkBio-101TC is Time & Attendance and Access Control Terminal to be associated with SilkID fingerprint reader, face recognition and RFID card functions. With the new SilkID fingerprint reader, the operation remains stable under strong light source and high preciseness of verification of wet and rough fingers. With latest facial algorithm and the innovation features, SilkBio-101TC is bringing you the whole new experience.
Technical Specifications | |
---|---|
Face Capacity |
2,000 |
Fingerprint Capacity |
3,000 |
ID Card Capacity |
2,000 (Optional) |
Algorithm |
ZKFinger 10.0 / ZKFace 7.0 |
Record Capacity |
100,000 |
Display |
2.8-inch TFT Screen |
Communication |
TCP/IP, USB-Host, Wi-Fi(Optional) |
Standard Functions |
Work Code, SMS, DST, Scheduled-bell, Self-Service Query, Automatic Status Switch, Photo ID T9 Input, Camera, 9 digit user ID, Built-in Battery, Multiple Verify Mode, External Bell |
Access Control Interface for |
Lock, Door Sensor, Exit Button, Alarm |
Optional Functions |
ID/Mifare, ADMS, External Printer |
Power Supply |
DC 12V 1.5A |
Operating Temp. |
0 °C- 45 °C |
Operating Humidity |
20%-80% |
Dimension |
180 x 154 x 34.2 mm |
uFace800 facial multi-biometric time & attendance and access control terminal supports up to 3,000 face templates, 4,000 fingerprint templates and 10,000 cards. With ZKTeco latest hardware platfrom and algorithm, it offers brand new UI and user-friendly operation interface to provide smooth user experience.
Technical Specification | |
---|---|
Display | 4.3-Inch Touch Screen |
Face capacity | 3,000 |
Fingerprint Capacity | 4,000 |
ID Card Capacity | 10,000(Optional) |
Log Capacity | 100,000 |
Communication | TCP/IP, USB Host, WiFi (optional) |
Standard Functions | Automatic Status Switch, Self-Service Query, Work Code, SMS, DST, T9 Input, 9 Digit User ID, Scheduled Bell, Photo ID |
Optional Functions | ID/MF Card, 3G, ADMS, 2000 mAh Backup Battery/td> |
Access Control Interface | Electric lock,Door sensor,Exit button,Alarm,Door bell |
Power Supply | 12V 3A |
Operating Temperature | 0 °C- 45 °C |
Oparating Humidity | 20%-80% |
Dimension | 193.6 × 165 × 111mm |
Package Weight( KG ) | 1.87 |
