SC103 is made with elegant design and professional surface treatment. The device have lock control, alarm, exit button, door sensor. The wiegand-in interface is used to connect external reader to construct master and slave system. Also the device can be used to connect with a control panel as a reader by wiegand-out interface. The operation can be done on the device through LCD display, also can be done on PC software and upload to the device through TCP/IP, RS232/485 communication. The USB-host is used for data download and upload, including user template and record etc. SC103 is suitable for house, small office and factory etc.
ID card Capacity |
30,000 |
Transaction Capacity |
50,000 |
Communication |
TCP/IP, RS485, USB-Host |
Weigand Ports |
Input & Output |
Interfaces |
3rd Party locks, door sensor, exit button |
Functions |
50 time zones, 5 groups, 10 combinations |
Power Supply |
12V DC 3A |
Optional |
Mifareã€Print Function |
Dimensions |
95 x 129 x 48mm |
SC105 is a RFID Access Control Terminal which possesses a 2.0-inch color display with graphical UI, enabling simple and easy control. It has a built-in auxiliary input function which enhances the flexibility to be connected with wired detector or emergency switch.
| Technical Specifications | |
|---|---|
ID card Capacity |
30,000 |
Transaction Capacity |
80,000 |
Communication |
TCP/IP, RS485, USB-Host |
Access Control Interface for |
3rd party electric lock, door sensor, exit button, alarm, doorbell |
Auxiliary Interface |
1ea for linkage function |
Wiegand Signal |
Output & Inputã€SRB |
Standard Functions |
Anti-passback |
Optional Functions |
Mifareã€Print Function |
Display |
TFT LCD Color Screen |
Power Supply |
DC 12V |
Operating Temperature |
0°C ~ 45°C |
Operating Humidity |
20% ~ 80% |
Dimension(L×W×H) |
130mm×94mm×52mm |
SDK |
Standalone SDK |
Software |
ZKAccess3.5 |
SC403 is an access control devices produced by ZKTeco, which is made with elegant design and professional surface treatment. The device have lock control, alarm, exit button, door sensor. The wiegand-in interface is used to connect external reader to construct master and slave system. Also the device can be used to connect with a control panel as a reader by wiegand-out interface. The operation can be done on the device through LCD display, also can be done on PC software and upload to the device through TCP/IP, RS232/485 communication. The USB-host is used for data download and upload, including user template and record etc. SC403 is suitable for house, small office and factory etc.
| ID card Capacity | 30,000 |
| Transaction Capacity | 50,000 |
| Communication | TCP/IP, RS232/485, USB-Host |
| Access Control Interface for | 3rd party electric lock, door sensor, exit button, alarm, Door Bell |
| Wiegand Signal | Output&Input |
| Standard Functions | Anti-passback, SMS |
| Optional Functions | Mifare, HID, Workcode, Webserver |
| Display | LCD |
| Power Supply | 12V DC |
| Operating Temperature | 0 ℃- 45 ℃ |
| Operating Humidity | 20%-80% |
| Dimension (L*W*H) | 143x95.5x39.5mm |
| Gross Weight | 0.8KG |
SC405 is a RFID Access Control Terminal which possesses a 2.0-inch color display with graphical UI, enabling simple and easy control. It has a built-in auxiliary input function which enhances the flexibility to be connected with wired detector or emergency switch.
| Technical Specifications | |
|---|---|
ID card Capacity |
30,000 |
Transaction Capacity |
80,000 |
Communication |
TCP/IP, RS485, USB-Host |
Access Control Interface for |
3rd party electric lock, door sensor, exit button, alarm, doorbell |
Auxiliary Interface |
1ea for linkage function |
Wiegand Signal |
Output & Inputã€SRB |
Standard Functions |
Anti-passback |
Optional Functions |
Mifareã€Print Function |
Display |
TFT LCD Color Screen |
Power Supply |
DC 12V |
Operating Temperature |
0°C ~ 45°C |
Operating Humidity |
20% ~ 80% |
Dimension(L×W×H) |
143mmx96mmx42mm |
SDK |
Standalone SDK |
Software |
ZKAccess3.5 |
SC700 is a 125 KHz proximity access control terminal incorporated with 3’’ TFT LCD. The color display and touch screen operation offer a user-friendly and easy menu management.
When connected with PC through Ethernet, SC700 is managed by ZKAccess 3.5 software. The software provides 2 applications, the access control and time attendance. It can also operate on standalone mode, and transfer data by USB flash drive.
The latest version of SC700 includes Wiegand Input port to connect external proximity reader and it can be used as a controller’s external reader using Wiegand Out port. As a professional access control device, it allows time zones and groups, holiday managements, linkage, anti-passback functions etc.
| Technical Specifications | |
|---|---|
Firmware |
PULL SDK |
Display |
3 Inches Touch Screen |
ID Card Capacity |
30,000 |
Logs Capacity |
100,000 |
Communication |
TCP/IP, USB Host |
Standard Functions |
ID card, Automatic Status Switch, T9 input, Multi-verification Method |
Access Control Interface |
3rd Party Electric Lock, Door Sensor, Exit Button, Alarm |
Wiegand Inferface |
Wiegand input&output |
Optional Functions |
Mifare Card |
Power Supply |
12V/3A |
Operating Temperature |
0°C - 45°C |
Operating Humidity |
20% - 80% |
Dimensions (H×W×D) |
160×104.7×36mm |
