F18 เครื่องควบคุมเปิด-ปิดประตูและบันทึกเวลาด้วยลายนิ้วมือรุ่นยอดนิยม ดีไซน์สวยล้ำ ทันสมัย แต่แข็งแรง ทนทาน เพราะผลิตจากวัสดุชั้นเยี่ยม หัวอ่านกระจก ทนต่อการกดกระแทก จอสีใช้งานง่าย กำหนดช่วงเวลาเข้า-ออกได้ด้วยฟังก์ชั่น Timezone ระบบ2ภาษา มาพร้อมเสียงพูดบอกการใช้งาน ดึงข้อมูลได้ง่ายด้วยช่องเสียบUSB เหมาะสำหรับติด ตั้งตามสถานที่ที่เน้นความปลอดภัยในการเข้า-ออกประตูเป็นอย่างยิ่ง
| Technical Specification | |
|---|---|
| Model | F18 |
| Fingerprint Capacity | 3000 |
| ID Card Capacity | 10,000(Optional) |
| Record Capacity | 100000 |
| Communication | TCP/IP ,RS232/485, USB-Host |
| Wiegand Signal | Output & Input |
| Standard Functions | Webserver, |
| Optional Functions | ID Card，Mifare Card |
| Access Control Interface | Electric lock,Door sensor,Exit button,Alarm,Door bell |
| Access Mode | Fingerprint only,Card only,Fingerprint+Card |
| Display | TFT LCD Color Screen |
| Language | English-Thai |
| Power Supply | 12V DC,3A |
| Operating Temperature | 0℃-45℃ |
| Oparating Humidity | 20%~ 80% |
| Dimension | 80x183x42mm(WxDxH) |
| Verification Speed | - |
F21 is the first time attendance and access control terminal applying the most advanced SilkID technology. It not only possesses outstandingly high identification rate towards dry, wet and rough finger, but also provides the utmost security by its live finger detecting capability.as well as photo taking function which enables attendance photo and Photo ID(optional). In addition, with the brand new ZMM220 hardware platform, its clock rate can attain 1.2GHZ. Such speedy hardware platform and fingerprint algorithm greatly enhance the speed of fingerprint verification.
| Technical Specifications | |
|---|---|
Display |
2.4-inch TFT LCD Color Screen |
Fingerprint Capacity |
3000 |
Card Capacity |
5000(Optional) ID or mifare card |
Transaction Capacity |
100,000 |
Sensor |
SilkID Sensor |
Algorithm Version |
ZKFinger VX10.0 |
Communication |
RS232/485, TCP/IP, USB-host |
Access Control Interface |
3rd Party Electric Lock, Door Sensor, Exit Button, Alarm, Doorbell |
Wiegand Signal |
Input, Output,SRB |
Aux. Input |
1ea for linkage function |
Functions |
DST,Automatic Status Switch, Anti-passback,Scheduled-Bell,Printer & Wireless door bell (Optional) |
Power Supply |
12V DC,3A |
Operating Temperature |
0 °C- 45 °C |
Operating Humidity |
20%-80% |
SDK and software |
Standalone SDK,ZKAccess3.5 software |
ICLOCK700 เครื่องควบคุมเปิด-ปิดประตูและบันทึกเวลาด้วยลายนิ้วมือ ที่ยกระดับการรักษาความปลอดภัย ขึ้นไปอีกขั้น ด้วยการเพิ่มฟังก์ชั่นกล้องถ่ายรูปในตัว เพื่อง่ายต่อการพิสูจน์เอกลักษณ์บุคคล โดยเครื่องจะถ่าย รูปทุกครั้งที่มีการสแกนนิ้ว แม้การสแกนนิ้วนั้นจะบันทึกสำเร็จหรือไม่ก็ตาม จึงป้องกันและตรวจสอบการทุจริตได้ 100% แม้ในยามไฟดับ ก็ไม่ทำให้การทำงานสะดุด ด้วยแบตเตอรี่สำรองของแท้จากโรงงานที่มาพร้อมเครื่อง ทั้งหมด นี้เป็นเทคโนโลยีความปลอดภัย ที่เราพัฒนา เพื่อคุณ
| Technical Specification | |
|---|---|
| Model | ICLOCK700 |
| Fingerprint Capacity | 8000 |
| ID Card Capacity | 10,000(Optional) |
| Record Capacity | 200000 |
| Communication | TCP/IP ,RS232/485, USB-Host |
| Wiegand Signal | Output & Input |
| Standard Functions | Workcode,Webserver,Camera,Built-in |
| Optional Functions | ID Card，Mifare Card,ADMS,Wi-Fi,GPRS,3G |
| Access Control Interface | Electric lock,Door sensor,Exit button,Alarm,Door bell |
| Access Mode | Fingerprint only,Card only,Fingerprint+Card |
| Display | 3.5-inch TFT Screen |
| Language | English-Thai |
| Power Supply | 12V DC,3A |
| Operating Temperature | 0℃-45℃ |
| Oparating Humidity | 20%~ 80% |
| Dimension | 225.2x166.0x46mm(Length x Width x Thickness) |
| Verification Speed | - |
TF1700 is one of the world’s smallest Ethernet connection-based fingerprint terminals, used for access control and time attendance features, with IP65 waterproof housing.
With its IP65 rated rugged waterproof and dustproof structure, TF1700 offers extra durability in harsh conditions such as outdoor environments. It is specially designed for standalone applications such as house, office, shop, garage, factory and others.
The 2013 version of TF1700 is equipped with a sensor cover to protect the optical reader and updated with new firmware that supports ZKAccess3.5 management software which has versatile features and powerful functions.
| Technical Specifications | |
|---|---|
|
Fingerprint Sensor |
Infrared detection fingerprint sensor |
|
Algorithm Version |
ZK Finger VX10.0 |
|
Communication |
TCP/IP, RS485, USB Host |
|
Fingerprint Capacity |
3,000 Fingerprints(8,000 Optional) |
|
Card Capacity |
10,000 Cards |
|
Log Capacity |
50,000 Transactions |
|
RF Card |
EM(standard)/Mifare(optional) |
|
Authentication |
Finger/PIN/Card |
|
Wiegand Signal |
Wiegand input&output |
|
Ingress Protection Rate |
IP65 |
|
Display |
128 x 64 OLED |
|
Keypad |
3 x 5 keypads & doorbell |
|
Sound and Interface |
Buzzer and multi-color LED |
|
Operating Voltage |
12VDC 3A |
|
Operating Temperature |
-10 °C~50 °C (14°F ~ 122°F) |
|
Dimension |
62.5mm×185mm×41.5mm (W×H×D) |
ProRF-T is an RFID access control terminal incorporated with 2.4 inches TFT LCD Screen .
The color display and new firmware structure offer a user-friendly menu for easy management, as well as photo taking capability that enables attendance photos and photo ID (optional). The new ZMM 220 hardware platform has a clock rate of 1.2 GHZ, greatly enhancing the speed verification. Touch keypad enables easy and convenient operations, such as managing users, accessing control parameter settings, or reading reports.
Capacity
Cards 50,000
Transactions / 100,000
User Photos / 3,000
Event Photos / 7,000
Communication
TCP / IP, USB Host, Wiegand Input / Output, Security Relay Box
Access Control Interface
Lock Relay Output, Alarm Output / Auxiliary Input, Exit Button / Door Sensor, Doorbell Output
Hardware
1.2GHz High Speed CPU
Memory / 128MB RAM / 256MB Flash
2.4 Inches TFT-LCD Screen
125KHz EM Reader / Mifare (Optional)
Hi-Fi Voice & Indicator
Tamper Switch Alarm
Touch Keypad
120° Wide Angle Camera
Standard Functions
Access Levels / Groups / Holidays
DST / Bell Schedule
Duress Mode (Password)
Anti-Passback
Record Query
Custom Wallpaper & Screen Saver
Special Functions
Multiple Verification Modes
Event Snapshot
User Photo (Optional)
ZK Encrypted Card (Optional)
Compatibility
Wiegand Slave Reader
ZKBioSecurity Software
Additional Info
Working Temperature: -10 °C ~ 50 °C
Dimensions: 195.5 × 87 × 35 mm.
Package Includes 12V 3A Power Supply
Power
Operating Voltage 12V DC
Current Draw < 500mA
MultiBio 700 is a new generation multiple biometric identification product. Integrating with Face, Fingerprint and PIN recognition and optional with RFID mode. It performs up to 20 verification methods all in a single device conveniently. MultiBio 700 stores 1500 faces and 2000 fingerprint templates and identifies users by 1:N mode. When users glance into the MutiBio700 camera, it captures the relative position, size, and shape of user’s eyes, nose, cheekbones, and jaw features. These parameters are used to create a biometric template which is then used to subsequently verify or identify each user. MultiBio700 can be used as a standalone access control reader by connecting a door lock, exit switch, alarm and door sensor to the relay contacts. The Wiegand IN and OUT ports can be used to connect 3rd party access control panels and peripherals. The MultiBio700 also includes a USB port for offline data backup/management.
With its IP65 rated rugged waterproof and dustproof structure, TF1700 offers extra durability in harsh conditions such as outdoor environments. It is specially designed for standalone applications such as house, office, shop, garage, factory and others.
The 2013 version of TF1700 is equipped with a sensor cover to protect the optical reader and updated with new firmware that supports ZKAccess3.5 management software which has versatile features and powerful functions.
| Technical Specifications | |
|---|---|
|
Display |
3-inch Touch Screen |
|
Face Capacity |
1,500 (1:N) |
|
Fingerprint Capacity |
2,000 |
|
ID Card Capacity(optional) |
10,000 |
|
Log Capacity |
100,000 |
|
Camera |
High Resolution Infrared Camera |
|
Sensor |
ZK Optical Sensor |
|
Communication |
TCP/IP, RS232/485, USB-host |
|
Access Control Interface for |
3rd party electric lock, door sensor, exit button, alarm, wired doorbell |
|
Anti-pass back Function |
Yes |
|
Wiegand Signal |
Input & Output |
|
Standard Access Control Function |
Time Zone, Group, Multi-identification Duress mode, Anti-passback, Tamper alarm |
|
Optional Functions |
ID Card, Mifare Card |
|
Power Supply |
12V DC |
|
Operating Temperature |
0 - 45 °C |
|
Operating Humidity |
20% -80% |
|
Dimension(L×H×D)mm |
275×100×195 |
|
Gross Weight |
0.87kg |
MultiBio 800 is a time attendance and access control terminal for face and fingerprint verification. Using ZK lastest ZKFACE 7.0 highspeed face recognition algorithm, it has extremely high verification speed and low error rate, and is able to effectively prevent duplicated registration.
With its high-resolution infrared night vision light and professional color duo camera, the terminal can carry out quick verification in any environment. What is more, it supports face, fingerprint, user ID, password, RFID card (optional) and various combination methods, in order to satisfy the demands of different users. Moreover, the TCP/IP communication supports connection across internet segments. Its auxiliary input function can be used for linking to Fire Alarm.
| Technical Specifications | |
|---|---|
|
Display |
2.8 inch TFT LCD Color Screen |
|
Face Capacity |
400 Face |
|
Fingerprint Capacity |
1000 Templates |
|
Card Capacity |
1000(Optional) ID or Mifare card |
|
Transaction Capacity |
100,000 Transactions |
|
Algorithm Version |
ZKFinger VX10.0 & ZKFace VX7.0 |
|
Communication |
RS485, TCP/IP, USB-host |
|
Access Control Interface |
3rd Party Electric Lock, Door Sensor, Exit Button, Alarm, Doorbell, Wiegand In/Out |
|
Aux. Input |
1ea for linkage function |
|
Standard Function |
DST, Automatic Status Switch, Anti-passback, Scheduled-Bell, PhotoID |
|
Power Supply |
12V DC,3A |
|
Operating Temperature |
0 °C- 45 °C |
|
Operating Humidity |
20%-80% |
|
SDK |
Standalone SDK |
|
Software |
ZKAccess3.5 |
uFace800 facial multi-biometric time & attendance and access control terminal supports up to 3,000 face templates, 4,000 fingerprint templates and 10,000 cards. With ZKTeco latest hardware platfrom and algorithm, it offers brand new UI and user-friendly operation interface to provide smooth user experience.
| Technical Specification | |
|---|---|
| Display | 4.3-Inch Touch Screen |
| Face capacity | 3,000 |
| Fingerprint Capacity | 4,000 |
| ID Card Capacity | 10,000(Optional) |
| Log Capacity | 100,000 |
| Communication | TCP/IP, USB Host, WiFi (optional) |
| Standard Functions | Automatic Status Switch, Self-Service Query, Work Code, SMS, DST, T9 Input, 9 Digit User ID, Scheduled Bell, Photo ID |
| Optional Functions | ID/MF Card, 3G, ADMS, 2000 mAh Backup Battery/td> |
| Access Control Interface | Electric lock,Door sensor,Exit button,Alarm,Door bell |
| Power Supply | 12V 3A |
| Operating Temperature | 0 °C- 45 °C |
| Oparating Humidity | 20%-80% |
| Dimension | 193.6 × 165 × 111mm |
| Package Weight( KG ) | 1.87 |
SilkBio-100TC is the first ever Time & Attendance and Access Control Terminal to be associated with SilkID fingerprint reader, face recognition and RFID card functions. With the new SilkID fingerprint reader, the operation remain stable under strong light source and high preciseness of verification of wet and rough fingers. With latest facial algorithm and the innovation features, Silkbio-100TC is bringing you the whole new experience.
| Technical Specifications | |
|---|---|
|
Face Capacity |
800 |
|
Fingerprint Capacity |
1500 |
|
ID Card Capacity |
2,000 (Optional) |
|
Record Capacity |
100,000 |
|
Display |
2.8-inch TFT Screen |
|
Communication |
RS232/485, TCP/IP, USB -Host |
|
Standard Functions |
Work Code, SMS, DST, Scheduled-bell, Self-Service Query, Automatic Status Switch ,Photo ID, T9 Input, Camera, 9 digit user ID, Built-in Battery, Multiple Verify Mode, External Bell. |
|
Access Control Interface for |
Lock, Door Sensor, Exit Button, Alarm |
|
Wiegand Signal |
Output |
|
Optional Functions |
ID/Mifare, ADMS |
|
Power Supply |
DC 12V 3A |
|
Operating Temp. |
0 °C- 45 °C |
|
Operating Humidity |
20%-80% |
|
Dimension |
173.0×159.0×36.1mm (Length×Width×Thickness) |
|
Net Weight |
490 g |
SilkBio-101TC is Time & Attendance and Access Control Terminal to be associated with SilkID fingerprint reader, face recognition and RFID card functions. With the new SilkID fingerprint reader, the operation remains stable under strong light source and high preciseness of verification of wet and rough fingers. With latest facial algorithm and the innovation features, SilkBio-101TC is bringing you the whole new experience.
| Technical Specifications | |
|---|---|
Face Capacity |
2,000 |
Fingerprint Capacity |
3,000 |
ID Card Capacity |
2,000 (Optional) |
Algorithm |
ZKFinger 10.0 / ZKFace 7.0 |
Record Capacity |
100,000 |
Display |
2.8-inch TFT Screen |
Communication |
TCP/IP, USB-Host, Wi-Fi(Optional) |
Standard Functions |
Work Code, SMS, DST, Scheduled-bell, Self-Service Query, Automatic Status Switch, Photo ID T9 Input, Camera, 9 digit user ID, Built-in Battery, Multiple Verify Mode, External Bell |
Access Control Interface for |
Lock, Door Sensor, Exit Button, Alarm |
Optional Functions |
ID/Mifare, ADMS, External Printer |
Power Supply |
DC 12V 1.5A |
Operating Temp. |
0 °C- 45 °C |
Operating Humidity |
20%-80% |
Dimension |
180 x 154 x 34.2 mm |
The SF300 is an IP based fingerprint terminal, which operate in both network mode and standalone mode. it can connect with ZKAccess3.5 software for access control and time attendance management.
Wiegand output makes SF300 flexible to connect with ZK or any 3rd party controllers as a slave reader, Additionally, wiegand input allows two units of SF300 to configure with each other and utilize Master & Slave solution, which requires user verification at both entrance and exit. Meanwhile, anti-passback function can be used to maximize the security
Auxiliary input interface allows SF300 to connect with an external source, for instance, a smoke detector or emergency switch. Once the linkage function is enabled through the machine menu, the device would generate an alarm signal and open the door in case of emergency.
| Technical Specification | ||
|---|---|---|
| LCD | 2.8 inch resistive touch screen | |
| Fingerprint Sensor | ZK Optical Sensor (500DPI) | |
| Algorithm | Version ZKFinger VX10.0 | |
| Communication | TCP/IP, RS485, USB Host | |
| Fingerprint Capacity | 1,500 | |
| Card Capacity (Optional) | 5,000 (EM/Mifare) | |
| Records Capacity | 80,000 | |
| Access Control Interface | Electric lock, Door sensor, Alarm, Exit button, Door Bell | |
| Wiegand Signal | Wiegand input & output | |
| Aux. Input | 1ea for linkage function | |
| Power Supply | DC 12V/3A | |
| Operating Temperature | 0 ~ 45°C (32°~113°F) | |
| Operating Humidity | 20 ~ 80% | |
| Dimension(L x W x H) | 105 x 105 x 34mm | |
SF400 is an IP based fingerprint terminal with both Network and Standalone operation modes. It is connectible with ZKAccess 3.5 software for access control and time attendance management.
| Technical Specifications | |
|---|---|
| Model | SF400 |
| LCD | 2.8 inch resistive touch screen |
| Fingerprint Sensor | ZK Optical Sensor (500DPI) |
| Algorithm Version | ZKFinger VX10.0 |
| Communication | TCP/IP, USB Host |
| Fingerprint Capacity | 1,500 |
| Card Capacity (Optional) | 5,000 (EM/Mifare) |
| Records Capacity | 80,000 |
| Access Control Interface | Electric lock, Door sensor, Alarm, Exit button, Door Bell |
| Wiegand Signal | Wiegand input & output |
| Aux. Input | 1ea for linkage function |
| Power Supply | DC 12V/3A |
| Operating Temperature | 0 ~ 45°C (32°~113°F) |
| Operating Humidity | 20 ~ 80% |
| Dimension(L x W x H) | 105 x 105 x 32mm |
MA300, one of the innovative biometric fingerprint readers for access control applications. Offering unparalleled performances by adopting an advanced ZK fingerprint algorithm for reliability, precision and excellent matching speed. It is metallic casing and IP65 rated which enables it to be resistant from water, dust and other outside damages.
P160 is a multibiometric identification time & attendance and access control terminal, which can connect with third party electric lock, door sensor, and exit button etc. With the latest palm/fingerprint identification algorithm and streamlined technology, it can hold 600 palm templates and up to 20,000 fingerprint templates without dividing into groups.
| Technical Specification | |
|---|---|
| Display | 2.8-inch TFT Color Display |
| Palm Capacity | 600 (Standard) |
| Fingerp,rint Capacity | 3,000 |
| ID Card Capacity | 10,000(Optional) |
| Log Capacity | 100,000 |
| Communication | TCP/IP, USB-Host, Wi-Fi(Optional) |
| Standard Functions | Automatic Status Switch, Self-Service Query, Work Code, T9 Input, 9 Digit User ID, DST, Scheduled-bell,SMS,RS232 Printer AC module 1:Exit Button, Door Lock, Alarm,12V OUT,AUX IN |
| Optional Functions | ID Card, MIFARE Card AC module 2: Exit Button, Door Lock, Alarm,12V OUT, AUX IN, Door Sensor, RS485, Wiegand IN/OUT. POE, 3G, Battery Module, ADMS |
| Power Supply | 12V 1.5A |
| Operating Temperature | 0 - 45 °C |
| Oparating Humidity | 20%~ 80% |
| Dimension | 179.95 x 134.94 x 38.5 mm |
| Verification Speed | ≤1 sec |
ZKTeco X7 คือ เครื่องแสนลายนิ้วมือและทาบบัตรรหัสผ่านโดยสามารถควบคุมการเปิด-ปิด
It can operate on standalone mode with the interface for third party electric lock, alarm, door sensor, exit button and doorbell.
Keypad operation is easy and convenient, such as, enrolling user, deleting user and accessing control parameter settings etc.
| Technical Specifications | |
|---|---|
Fingerprint Capacity |
500 Templates |
Card Capacity |
500 |
Sensor |
ZK Optical Sensor |
Access Control Interface |
3rd Party Electric Lock, Door Sensor, Exit Button, Alarm, Doorbell |
Size |
88*88*33.6 mm |
Operating Temperature |
0 °C- 45 °C |
